Fukuda FD-9G Line Detector

Fukuda FD-9G Detector

This is an accurate Laser Line Detector from Fukuda Lasers.

It extends the range of "pulse output" GREEN LINE lasers (Not Rotary Lasers) up to 50m for both indoor & outdoor site work.

This Detector is only compatible with specific Laser Levels. Please ensure you refer to the "Technical Specification" below to ensure compatibility.

Features

For use with Fukuda GREEN beam "pulse output" lasers.

Working range 50m

Audible indication of line level

Visual LED indication of line level

Mounting clamp bracket included for use with staffs/rods

Waterproof to IP54

Warranty: 1 Year

Specification

Sensitivity setting: fine 1.5mm / coarse 2.5mm

Frequency: 10kHz

Laser reception window: 20x40mm

Auto power off: 10 minutes

Power voltage: 9V dc

Power supply: 1 x 9V alkaline battery

Continuous operating time: 15 hrs

Waterproof: Yes to IP54

Operating temperature range: -10 to +40 deg C

Storage temperature range: -10 to +50 deg C

Instrument size: 165 x 51 x 27 (mm)

Weight: 160 grams with battery.

Compatibility

Please check compatibility below:

Model	Compatible
Fukuda EK-268G	Yes
Fukuda FLG-411QG	Yes
Any other Brand or Model	No

Comprises of

Fukuda FD-9G Detector

9V Alkaline Battery

Staff Mounting Bracket

Warranty: 1 Year
